Monel 400 Data Sheet - UNS N04400 Composition, Mechanical, Physical
This Monel 400 data sheet (also Monel 400 datasheet, Monel 400 spec sheet, UNS N04400 data sheet, Alloy 400 data sheet) is a quick-reference card for the nickel-copper solid-solution alloy at 63 to 70 percent nickel and 28 to 34 percent copper, registered as UNS N04400 / Werkstoff 2.4360. Use this page in tender packs and procurement files. Monel® is a registered trademark of Special Metals Corporation; TorqBolt is not authorized by, affiliated with or endorsed by Special Metals.
Chemistry at a Glance
Per ASTM B127, ASTM B164, ASTM B564 and ASTM F468 Table 1. Cobalt is counted as nickel. Full treatment on the chemical composition page.
| Element | Symbol | Range (wt percent) |
|---|---|---|
| Nickel + Cobalt | Ni | 63.0 - 70.0 |
| Copper | Cu | 28.0 - 34.0 |
| Iron | Fe | 2.5 max |
| Manganese | Mn | 2.0 max |
| Carbon | C | 0.30 max |
| Silicon | Si | 0.50 max |
| Sulphur | S | 0.024 max |
Mechanical at a Glance
Annealed minimums per ASTM B164 and ASTM F468 bolt class. Elevated-temperature and cold-worked tempers on the mechanical properties page.
| Property | Value (US) | Value (SI) |
|---|---|---|
| Tensile strength, min | 70 ksi | 480 MPa |
| Yield strength, 0.2 percent offset, min | 25 ksi | 170 MPa |
| Elongation in 2 inch, min | 35 percent | 35 percent |
| Hardness, F468 bolts, max | HRC 25 | HB 254 |
| Reduction of area, typical | 60 percent | 60 percent |
Physical Properties
Room-temperature constants for annealed bar. Detail pages: density, melting point, magnetic permeability, machinability.
| Property | Value | Unit |
|---|---|---|
| Density at 20 degrees Celsius | 8.80 | g/cc |
| Melting range | 1300 to 1350 | degrees Celsius |
| Modulus of elasticity | 179 | GPa |
| Mean coefficient of thermal expansion, 20 to 100 C | 13.9 | micrometre per metre per kelvin |
| Thermal conductivity at 20 C | 21.8 | W per metre per kelvin |
| Electrical resistivity at 20 C | 0.547 | microohm metre |
| Relative magnetic permeability at 20 C | 1.0 to 1.05 | non-magnetic in standard service |
Governing Standards
Purchase against the form-specific ASTM number plus UNS. Sour service adds NACE MR0175. European equivalence: DIN 17743 NiCu30Fe (Werkstoff 2.4360).
- ASTM B127 plate, sheet, strip
- ASTM B164 rod, bar, wire
- ASTM B165 seamless pipe and tube
- ASTM B564 forgings, Table 1 UNS N04400 Class A
- ASTM F468 bolts, hex cap screws, socket head cap screws and studs
- ASTM F467 nuts
- DIN 17743 NiCu30Fe, Werkstoff 2.4360
- NACE MR0175 / ISO 15156-3 H2S service
- UNS N04400
Application Snapshot
Four service blocks dominate: hydrofluoric acid and HF alkylation piping, valve and bolting (chromium-free composition is immune to HF stress corrosion); seawater and marine structures including offshore platform fastening; sour service oil and gas under NACE MR0175 Table A.7; and naval, hydrographic and minesweeping equipment needing relative magnetic permeability below 1.05.
Frequently Asked Questions
Is there a downloadable Monel 400 PDF data sheet? A PDF copy is emailed against project enquiries. Send application, size and quantity to info@torqbolt.com or WhatsApp +91-22-66157017; the PDF returns inside one working day.
Where can I get a certified Monel 400 mill test certificate (MTC)? Every TorqBolt batch ships with an EN 10204 type 3.1 MTC reporting actual cast chemistry against ASTM B127, B164, B564 or F468, plus mechanical results, heat number and PMI. Type 3.2 MTC with independent witness verification is available for sour service and pressure equipment.
